GT3582R DBB turbo w/ 1.01 A/R NR DIV T3 Tbn Hsg "GT VBAND 3" conical exit

Quantity in Basket: None
Code: GRT-TBO-G97
Price: $1,795.00
Shipping Weight: 3.00 pounds

Product Description:

Garrett GT3582R dual ball bearing turbo with 1.01 A/R NiResist divided T3 "GT VBAND 3" conical exit turbine housing. Supports 650HP+ potential flow.
Product Specifications:

Compressor Wheel Inducer: 61.4mm
Compressor Wheel Exducer: 82mm
Compressor Wheel Trim: 56
Compressor Housing: 0.70 A/R
Turbine Wheel Inducer: 68mm
Turbine Wheel Exducer: 62.3mm
Turbine Wheel Trim: 84

Coolant (Water) & Oil Fittings, Flanges, and Components Solutions:

Coolant - Water Options (Requires 2 units): 14mm Coolant Fitting & Lines
Oil feed options: -4 AN with built-in Restrictor - Product Code: ATP-OIL-021)
Oil drain flange - Product Code: ATP-FLA-010
Oil drain gasket - Product Code: GRT-GSK-008

T3 Divided Inlet Flange (for Turbo Manifold): Product Code:ATP-FLS-068
T3 Divided Inlet Gasket: Product Code:ATP-GSK-015
V-Band "GT" 3 Inch Outlet Flange (for Downpipe): Product Code:ATP-FLS-246
V-Band Outlet Clamp: Product Code:CLC-CLA-048

Compressor & Turbine Maps:

Applicable Garrett Part Numbers:

714568-5012S
