The next step in evolution.
The Garrett® Evo X GTX Turbo
Upgrade allows you to push
your AWD, rally-bred monster
further than ever before! How
about up to an estimated 560
HP with the Garrett® GTX3071R
or a tire-shredding estimated
640 HP with the Garrett® GTX3076R? It is now possible
with the newest bolt-on offering
from the world's leader in
turbocharging!
Each turbo has been
meticulously designed to be
a bolt-on upgrade with no
fabrication, cutting or welding
required.
The Garrett® Evo X Turbo
Upgrade features a specifically
designed twin-scroll turbine
housing that mates up directly
to the Evo X's stock exhaust
manifold and down pipe to allow
aftermarket exhausts to be used
without worrying about fitment.
The turbine housing allows
the retention of the stock
exhaust heat shield for better
temperature control as well as a
stealth look.
The ported shroud compressor
housing reduces surge
occurrence during operation
and mates directly to the intake
piping while maintaining the
stock outlet position.
The Garrett® patented dual
ball bearing center housing is
standard on both turbocharger
options for unmatched power
handling and unbeatable
response.
Kit Contains:
Choice of 4 Garrett® dual ball
bearing, application-specific
turbochargers
All necessary lines, gasketsand hardware
Installation Instructions
Twin Scroll GT3071R
Twin Scroll GT076R
Twin Scroll GTX3071R
Twin Scroll GTX3076R
Twin Scroll GT3582R
Twin Scroll GTX3576R
Twin Scroll GTX3582R
Evo X Twin Scroll GTX3576R
Evo X Twin Scroll GT3582R
Evo X Twin Scroll GT3076R
|
