Catalog Home > Turbos & Housings > Garrett GT - Ball Bearing > GT Turbos With Special Turbine Housings > GT3076R With Special Housings

Garrett GT3076R Std Ported T04E 4" in / 2" OUT with .92 A/R T3 INT W/G - 6 BOLT (NOT RB25DET!) Exit

Quantity in Basket: None
Code: GRT-TBO-J54
Price: $1,241.37
Shipping Weight: 3.00 pounds

Quantity:

Garrett GT3076R Std Ported T04E 4



Product Description:
    Garrett GT3076R standard ported T04E 4" in / 2" out turbo with .92 A/R T3 internal wastegate, 6 bolt (not RB25DET!) exit turbine housing. 525+HP potential flow.

    Note: This turbine housing bolt pattern looks similar to, but is different than the Nissan RB25DET bolt pattern. The RB25DET series turbos can be found here.
Product Features:
  • Genuine Garrett GT Aero compressor wheel
  • Genuine Garrett GT Inconel turbine wheel
  • Dual ball bearing CHRA rotating assembly

Product Specifications:
  • Compressor Wheel Inducer: 57mm
  • Compressor Wheel Exducer: 76mm
  • Compressor Wheel Trim: 56
  • Compressor Housing A/R: 0.60
  • Turbine Wheel Inducer: 60mm
  • Turbine Wheel Exducer: 55mm
  • Turbine Wheel Trim: 84
Coolant (Water) & Oil Fittings, Flanges, and Components Solutions: Compressor & Turbine Maps: Applicable Garrett Part Numbers:
  • 836028-5003S
  • 700382-5012


Related Item(s)
Related Parts:
Code Name Price
ATP-FLS-369 Flange, Downpipe, 6 Bolt, 6BT3, not RB25DET $39.00
