Catalog Home > Turbos & Housings > Garrett GTX Gen2 > Garrett GTX3584RS Gen2 Variants > Garrett GTX3584RS Gen2 - All Variants

Turbocharger, Gen2 GTX3584RS w/ T3 UND T31 NARROW VBAND .82 A/R hsg, HOSE CONNECTION COMP

Quantity in Basket: None
Code: GRT-TBO-J41
Price: $3,005.78
Shipping Weight: 3.00 pounds

Quantity:

Turbocharger, Gen2 GTX3584RS w/ T3 UND T31 NARROW VBAND .82 A/R hsg, HOSE CONNECTION COMP



Product Description:
    Garrett Gen2 GTX3584RS with .82 A/R T3 undivided T31 narrow v-band turbine housing and hose connection compressor housing. Compact package capable of 1,000 HP.
    • Advanced aerodynamics Garrett GTX GEN2 billet aluminum compressor wheel
    • Ultra high flow "RS" blade profile turbine wheel
    • Dual ball bearing CHRA rotating assembly
    • Compact package capable of 1,000 HP
Product Specifications:
  • Compressor Wheel Inducer: 67 mm
  • Compressor Wheel Exducer: 84 mm
  • Compressor Wheel Trim: 64
  • Compressor Housing: T04S Frame with a 4" inlet and 2.5" v-band outlet w/ Anti-Surge
  • Turbine Wheel Inducer: 68 mm
  • Turbine Wheel Exducer: 62 mm
  • Turbine Wheel Trim: 84
Coolant (Water) & Oil Fittings, Flanges, and Components Solutions: Compressor & Turbine Maps: Applicable Garrett Part Numbers:
  • 846098-5001S
